992-01
Water Tapping Set for air valve set 992

Can be used instead of the air release valve in an air valve set ( Model no. 992 ). Use Water tapping set for flushing or sampling device under pressure.

Max. operating pressure: 250 psi / 17.2 bar

Advantages:
- Installation and dismantling under pressure
- Use for flushing and venting after initial start-up and/or filling of pipelines
- Controlled water tapping via ball valve
- Pressure testing

Material: Pipe, screw connection and elbow: Steel
Fitting: GJL-250 ( GG-25 ), fluidized bed epoxy powder coated
Push fitting: POM, NBR
Ball valve: brass
Medium Water
Order Nr.

Pipe cover depth

H

Height

Pipe Cover Depth
Medium Weight Specification Basket
9922900755
1,00 755 mm 2.2 ft (755 mm) 3.3 ft (1.00 m) 16,53 LBS
Wish List

Other dimensions on request!
