Automatic air release and vacuum valve, short body, Fiberglass Reinforced PA66
Technical features
| Connection | Female thread |
| Operating pressure | 150 PSI (10 bar) |
| ventilation cross-section | 0,74 in² (480 mm²) |
| Continuous operation | yes |
| Max. venting capacity | 153 cfm (260 m³/h) |
| Special functions | Only air release, Only air intake Venting stop: for lines purged with compressed air |
| Flushing connection | yes |
| Area of application | Plant engineering, Raw Water, Reclaim Water, Industrial application |
| Notice 1 | 2" FNPT on request |
Materials
Body: Fiberglass reinforced PA
Float Rod: Stainless Steel
Outlet: Elbow Polyethylene
Float: PP
O-Ring: NBR
Damper Ring: EPDM
Diaphragm: HNBR
Profile Clamp: Stainless Steel
Ball Valve 3/8”: Stainless Steel
Diaphragm Cup: POM
Outer-ring: Stainless Steel
Float Rod: Stainless Steel
Outlet: Elbow Polyethylene
Float: PP
O-Ring: NBR
Damper Ring: EPDM
Diaphragm: HNBR
Profile Clamp: Stainless Steel
Ball Valve 3/8”: Stainless Steel
Diaphragm Cup: POM
Outer-ring: Stainless Steel
Further information
Description
Downloads
Description:
For operating ranges: 0 – 150 PSI (10 Bar), outdoor application possible
Features:
Automatic and infinitely variable air valve for waste water.•Valve comes with a 316 Stainless Steel bushing allowing a 2" or 3" FNPT connection.
The low weight of the air valve allows for an easy and quick install.
Recommended for outdoor application in frost-free areas.•Operating Pressure: 150 PSI (10 Bar)•Operating Range: 0 – 150 PSI (0 - 10 Bar)
Valve body made of fiberglass reinforced PA 66.
Valve seat does not contact the media (air cushion).•All mechanical parts are manufactured of corrosion-resistant materials.
Valve Maintenance:
The valve can be quickly opened and closed during maintenance andcleaning due to the profile clamp made of stainless steel.
Air valves must be tested for function and maintained at least once per year.
Features:
Automatic and infinitely variable air valve for waste water.•Valve comes with a 316 Stainless Steel bushing allowing a 2" or 3" FNPT connection.
The low weight of the air valve allows for an easy and quick install.
Recommended for outdoor application in frost-free areas.•Operating Pressure: 150 PSI (10 Bar)•Operating Range: 0 – 150 PSI (0 - 10 Bar)
Valve body made of fiberglass reinforced PA 66.
Valve seat does not contact the media (air cushion).•All mechanical parts are manufactured of corrosion-resistant materials.
Valve Maintenance:
The valve can be quickly opened and closed during maintenance andcleaning due to the profile clamp made of stainless steel.
Air valves must be tested for function and maintained at least once per year.
Notes:
- 2" FNPT on request
