Water Tapping Set for air valve set 992

Models

Operating pressure	250 PSI (17.2 bar)
Notice 1	Other dimensions on request!

Pipe, screw connection and elbow: Steel
Fitting: GJL-250 ( GG-25 ), fluidized bed epoxy powder coated
Push fitting: POM, NBR
Ball valve: brass

Description Downloads

Scroll to see more →

Grouped product items
Item number	Medium	Pipe Cover Depth	A-Text	Qty
9922900755	water	3.3 ft (1.00 m)	9922900755 Flushing and water tapping set for air valve assembly, consisting of a connecting piece with double O-ring seal, piping with elbow fitting and clamping point and ball valve with female thread 2". Material: Piping: steel, galvanized Fitting: GJL-250, corrosion protection due to epoxy powder coating inside and outside acc. to quality assurance RAL-GZ 662 of the Gütegemeinschaft Schwerer Korrosionsschutz GSK (Quality Association for Heavy-Duty Corrosion Protection) considering DIN 3476 (P) and DIN 30677-2 (coating thickness: min. 250 μm, zero-porosity at 3 kV, adhesion inside at outside min. 12 N/mm² after exposure to hot water, proof of suitability for potable water applications, external monitoring through neutral testing institute) Connecting piece: POM Ball valve: brass Medium: potable water Max. operating pressure: 16 bar Pipe cover depth of air valve set: 3.3 ft (1.00 m) Overall Height air valve set: 2.5 ft (755 mm)		Height 2.5 ft (755 mm) Weight 16,53 LBS Delivery Time by appointment
Height 2.5 ft (755 mm) Weight 16, 53 LBS Delivery Time by appointment
